60 Ton Shop Press with PLC and Portable Power Unit 460V, 3Ph
Backorder
Only 2 left
Flyers - Edwards
Stock Number:
ED9-HAT8080
$23,499.00
60 Ton Shop Press with PLC and Portable Power Unit 460V, 3Ph
This 60 Ton Shop Press includes a Programmable Logic Control (PLC) to maximize your efficiency with shorter cycle times - over a 50% time savings. With a large work table area, this Shop Press accepts both standard and custom tooling to press bearings, bend metal or straighten a part. The rolling cylinder, open-sided design, and electric foot pedal make this machine simple to use. This Shop Press package includes a Portable Power Unit and is ready to PLUG IN & POWER UP.
20' quick-connect hoses for simple "plug & play" operation
Accepts a variety of standard and custom tooling
Electric foot pedal with integrated jog control
Hydraulic-assist adjustable work table heights to maximize operator safety includes lift chains and bracket
Magnetic PLC control box mounts anywhere on the shop press for user performance and comfort
Open-sided design allows longer material to pass through the frame
Programmable Logic Control (PLC) allows operators to create repeatable actions, improving efficiency
Requires an Edwards Ironworker with PowerLink System or a Portable Power Unit to operate (included)
Rolling cylinder provides maximum adaptability
| Stock Number | ED9-HAT8080 |
|---|---|
| Gross Weight (Lbs) | 2300 |
| Minimum Ram Speed (In./Sec) | .330 |
| Minimum Return Speed (In./Sec) | .456 |
| Net Weight (Lbs.) | 2300 |
| Product Dimensions (In.) | 48 x 54 x 86 |
| Prop 65 | Cancer and Reproductive Harm |
| Rating (Tons) | 60 |
| Stroke (In.) | 12-1/4 |
| Weight (Lbs.) | 2300 |
| Work Table (In.) | 39-1/4 x 42 |
